Pyronix (MC1/SHOCK-WE) 2-Way Wireless Mag Contact/Shock Sensor, White

Pyronix (MC1/SHOCK-WE) 2-Way Wireless Mag Contact/Shock Sensor, White

The product is specifically designed to be placed in positions where it is necessary for a shock sensor and magnetic contact to be present, such as on doors and windows; two sensors in one!

The sensors can both be learned separately to the panel allowing separate shock and magnetic contact transmissions of alarm signals to be sent to the panel. They can also be learned individually, if for some reason either the shock or the magnetic contact is not required.

Signal Strength Indicator (SSI)
One of the key advantages of implementing of the SSI technology is to allow the installer to view the wireless transmission signal strength on both the control panel and wireless devices in real time.

Two Way Wireless Technology
Each wireless device on the Enforcer system, including movement detectors is a transmitter and a receiver. The wireless technology used on the Enforcer system holds a significant advantage over one way and some two way wireless products currently available on the market.

ABS plastics
2mm polished finish, reduces electrostatic interference.

One-Push-To-Learn

Assigning wireless devices to the system is made simple and quick by the One-Push-To-Learn feature.
1. Choose an input to learn the device to
2. Remove the plastic insulator between the battery and positive contact and press LEARN button
3. Input learnt
Quick, Simple and Efficient!

Key Features:

• Signal Strength Indicator on the Device
• 868MHz Transceiver FM technology
• 1 Input
• External Tamper input
• Also Available in brown

Technical Specifications:

Security and safety sensors technical characteristics

• Magnetic contact : Yes
• Shock sensor : Yes
• Tamper protection : Front and rear
• LED sensor test : Signal, Battery, Alarm, Tamper
• Terminal for N/C input and reed switch : Yes
• Magnet included : Yes
• Tamper input : Yes

Enforcer two-way wireless technology

• Signal Strength Indicators (SSI) : Yes
• Instant two way device control (ITDC) : Yes
• Pyronix high security two way wireless data encryption protocol (TDE) : Yes
• Pyronix intelligent jamming detection : Yes
• Programmable wireless supervision time : Yes
• 868MHz transceiver FM technology : Yes
• One push to learn : Yes
• Tranmission method : Fully encrypted rolling code
• Transmission range : 1.6m in open space

Environmental and operating features

• Storage temperature : -20°C to 50°C
• Certified operating temperature : -10°C to 40°C
• Nominal operating temperature : -10°C to 50°C
• Physical dimensions (H x W x D) : 30 x 130 x 35mm
• Magnet : 17 x 56 x 12.7mm

Electrical & battery

• Battery type : 3.0V CR123A lithium battery
• Battery life : 2 years
• Threshold : 2.5V +/- 5% at 25°C

Certifications and warranty

• Electrical conformity : CE
• EN Certificate : EN50131-2-6:2008, EN50131-5-3:2005+A1:2008, PD6662:2010
• Certification type : Self certified
• Environmental class : II
• Warranty : 2 years
• Security Grade : Grade 2
