Bell, SPA8F, Standard 8 Button Door Entry System (Flush Panel)

Bell, SPA8F, Standard 8 Button Door Entry System (Flush Panel)

They are manufactured from 3 mm brushed anodised aluminium with an integral grill that protects the speech unit and complements the surface back box. The grill has fixings on the rear to firmly secure a model 61 speech unit.

A single push-button with integral nameplate is provided for each station including an optional Tradesmans button. This push-button has a versatile design whereby pressure from any part of the nameplate will initiate a call. The nameplate can easily be removed from the front for replacement or amendment of the name or number on the paper insert (included with each button).

Optional backlighting can be achieved by fitting a model SPA-LAMP lamp unit to each push-button.

• Standard 8 Buttons
• Manufactured from 3 mm brushed anodised aluminium
• Surface Panel: 470 x 83mm(HxW)
• BackBox: 459 x 73 x 35mm(HxWxD)
• Fixings on the rear to firmly secure a model 61 speech unit

Speech Unit 61

This compact unit is fitted to the entrance panel on all our current door entry systems(except as indicated below). The unit provides two-way speech and has an individual volume control for both microphone and speaker. This universal product can be powered from either 12V AC or 12V DC depending on the model of telephone used.

Dimensions: H = 97mm, W = 58mm, D = 24mm

Note: All panels up to 10 buttons require a model 61 speech unit.
