TDSI, 5002-0396, Exprox2 K Square Reader with Keypad
- Brand:TDSi
- Product Code:5002-0396
- Availability:Please Call or Email to Checkout
TDSI, Exprox2 K Square Reader with Keypad (5002-0396)
These high quality access control card readers provide robust, reliable performance through contactless technology for a wide range of applications. Supplied with both a reader and keypad, this unit provides additional security if desired the user having to present their card and enter their PIN before access is granted. With a range up to 20cm, these fully featured readers are available in a number of options for maximum design flexibility.
EXprox2K is a range of high-performance contactless proximity readers from TDSi. EXprox2K is designed to be mounted in a standard electrical back-box making for a neat and simple installation. All products are supplied with a choice of covers allowing the look of the reader to be changed to suit its surroundings.
Key Features:
- Combination of both card reader and keypad
- ABS plastic housings with a choice of alternative clip-on covers
- Blue back-lit keypad
- Fully encapsulated unit is suitable for internal or external installation
- Audible and visual indication of cards read and access status
Key Benefits:
- Additional security - one or two factor authentication before access is granted
- Reader can be tailored to suit different aesthetic requirements
- May be mounted internally or externally
- Allows connection to all standard access control panels
Specifications:
- Dimensions: 102 x 102 x 20 mm. Connector including terminal block protrudes by 11 mm from rear face.
- Weight: 270 g
- Operating environment: -20°C to +55°C, 0 to 95 %RH (non-condensing)
- Power supply: 9 to 16 VDC, 75 mA max
- Operating frequency: 126 kHz (nominal)
- Card technology: EM4100, EM4102, EM4200 and compatible
- Sounder: Integral with external control
- LEDs: 2 red and green both with independent external control. Bi-colour input capability for connection to TDSi access control units.
- Read range: 150 mm (nominal) with ISO card, 70 mm (nominal) with tag
- Output formats: Mag stripe, 26-bit Wiegand
