Visonic, 0-1046-0, Next Plus Wired

Visonic, 0-1046-0, Next Plus Wired

Next ^® + PIR   is the most complete solution available in detectors with high characteristics. With an elegant design, its use is ideal in residential installations, offices and small shops, where aesthetics is also important.

Next + PIR   offers a range of up to 15m.

Patented Technologies: True Digital FM, provides greater reliability and stability in signal processing. Tru Motion Recognition. (TMR), Processing with 2 selectable "event" ranges for false alarm prevention. 3D cylindrical optics with TSI for volumetric detection without dead zones. Next + PIR incorporates a patented lens that combines the cylindrical and Fresnel optical segments providing greater sensitivity and coverage.

Technical Specifications:

• Supply voltage: 9 to 16 VDC
• Current in STBY: 8 mA at 12VDC
• Output Alarm: Relay, 100 mA
• RFI protection: greater than 20 V / m (up to 2GHz)
• Sensitivity adjustment: 1 or 2 events
• Operating temperatures: -10 ^o C to 50 ^o C
• Dimensions: 94.5 x 63.5 x 49.0 mm
• Mounting height: 1.8 to 2.4 m

For more details, please refer with our attached datasheet.
