Optex, SL-350QFR[C], Smart Line Quad Beam 100m Photo Beam - 4 Channel

Optex, SL-350QFR[C], Smart Line Quad Beam 100m Photo Beam - 4 Channel

Optex offers a less expensive and more efficient solution with SL-350QFR.

Typical perimeter systems require expensive trenching or much time for installation. Expensive wire conduit runs and concrete work is unnecessary, allowing installers to save time and money.

Features:

• Long distance 100m / 350ft.
• Wireless ready
• Weather protection IP65
• Long battery life 4 to 10years
• Sniper viewfinder with 2X magnification
• Spacious back box

Technical Specifications:

• Maximum detection range: 100 m/350 ft
• Maximum arrival distance: 100 m/350 ft
• Detection method: Quad infrared beam interruption detection
• Interruption time: Variable between 50/100/250/500 ms (4 steps)
• Alarm output: Form C-Solid State Switch: 3.6 VDC, 0.01 A
• Alarm period: 2 sec (±1) (Nominal)
• D.Q. output: Form C-Solid State Switch: 3.6 VDC, 0.01 A (Receiver only)
• Low battery output: N.C. (mechanical switch): 3.6 VDC, 0.01 A
• Tamper output: N.C. (contact output): 3.6 VDC, 0.01 A. Opens when cover, main unit or back box is removed.
• Operating temperature: -20°C - +60°C (-40°F - 140°F)
• Operating humidity: 95% (max.)
• Alignment angle: ±90° Horizontal, ±10° Vertical
• Dimension: H x W x D mm (inch) : 452 (17.9) x 83 (3.3) x 138 (5.4)
• International protection: IP65

For more details, please refer with our attached datasheet.
