Knight Plastics (PDC30B4K72K2) Flush Contact 6 Core Brown 4k7/2K2 (Grade 2)

Knight Plastics (PDC30B4K72K2) Flush Contact 6 Core Brown 4k7/2K2 (Grade 2)

The PDC30B4K72K2 is Flush Contact 6Core 4K7/2K2 (Grade 2)

Key Features:

• EN50131-2-6 Compliant to Grade 2
• Environmental Class 3
• Includes 4K7 resistor for alarm and 2K2 resistor for EOL
• Suitable for use with Castle, Menvier, Pyronix, Scantronic & Texecom panels
• 6 core
• 1 metre
• Fits into prepared recess
• Dimensions: 27.8mm x 8mm dia
• Operating Gap: 15mm
• Materials: High Impact Polystyrene
• Colours: White or Brown (Suffix B)

Specifications:

Description:

• Grade 2 Class III
• 6 Core Push Fit Ribbed Flush Contact
• Single Reed, pre-fitted pre-set resistors.

Operating Gap:

• 15mm (Approx)

Materials:

• High Impact Polystyrene

Magnet:

• Ferrite or Alnico V

Contact Material:

• Rhodium

Voltage Range:

• 1 – 100v DC
• 125v AC Max

Switching Current:

• 500mA Max DC
• 500mA Max AC

Temperature Range:

• -40oC - +50oC

Colours:

• White (No Suffix)
• Brown (Suffix B)
• Fixing Screws Provided
