Intelligent Remote Digital OP/Analog IP Submodule (ISM02)
- Brand:CYTECH
- Product Code:ISM02
- Availability:Please Call or Email Us to Check Availability
Intelligent Remote Digital OP/Analog IP Submodule (ISM02)
The ISM02 Digital Output/Analog Input Submodule of IRIO has 4 Open-collector and 4 Analog (0-10V) Inputs.
Connections
- OP1/+12V/OP2 Output 1,2 connections. Centre is +12V
- OP3/+12V/OP4 Output 3,4 connections. Centre is +12V
The Outputs are open-collector outputs, i.e. transistor outputs which pull down to ground when turned on.
- INP1/COM/INP2 Input 1,2 Connections. Centre common ground
- INP3/COM/INP4 Input 3,4 Connections. Centre common ground
Delivery Note: 1-2 weeks Lead Time Applicable.
