Elmdene, RAPIER-G3S-NC, Rapier External Sounder Galvanised Steel, NO COVER - G3

Elmdene, RAPIER-G3S-NC, Rapier External Sounder Galvanised Steel, NO COVER - G3

The Rapier range of high quality sounders has been upgraded to fully meet the requirements of EN50131-4:2009 Grade 3 and 4 and include a host of new and improved features.   The sounders now include a diagnostic LED, audible front and rear tamper status, versatile trigger options and control panel dependent end of line resistors also help make installation easier.

Key Features:

• Designed to meet the requirements of EN50131-4:2009 Grade 3 and 4
• Low power operation: 10mA standby, 220mA full alarm - siren  & strobe
• 113dB(A) sound output
• Battery and piezo self-test with fault output
• Remote test input
• Ring line monitoring
• Silent engineer mode
• Range of selectable integral EOL tamper resistors
• Portrait or landscape mounting
• Audible tamper status to assist commissioning
• LED strobe
• Twin flashing comfort LEDs
• Full SAB capability
• Selectable positive hold-off signalling
• Diagnostic LED
• Cascade tamper for multiple sounder installations
• Drill detection (G4S model only)
• Two interna spirit level to aid vertical or horizontal mounting
• Screen printing available
• 3 year warranty

Specifications:

• Sound out (at 1m): 113dBA
• Operating voltage: 9 – 15V dc
• Siren operating current: 180mA
• Strobe operating current: 40mA
• Standby quiescent current: <10mA
• Cut-off timer: 5s, 5, 10, 15 mins
• L x W x D: 342mm x 221mm x 55mm
• Weight: 3.75kg

For more details, please refer with our attached datasheet.
