Elmdene, G2401BM-R, 24V Switch Mode PSU (27.6V) 2Amp to load + 0.5A battery charging

Elmdene, G2401BM-R, 24V Switch Mode PSU (27.6V) 2Amp to load + 0.5A battery charging. Efficient Switch Mode operation. Mains and Battery monitoring with independent volt free fault outputs. Deep discarge protection. Multi LED status indication. Fit up to 2x17Ah battery. 'R'

The new 24V G Range BM Series power supplies has been designed for access control, CCTV, fire systems (where compliance with EN54-4 is not required) and general purpose applications. The products use energy efficient switch mode technology and have a universal mains supply input (90—264V ac).

Elmdene’s FOM4 or FOM8 units can be fitted to give 4 or 8 independent fused outputs if required.

The modular range consists of 1A, 2A, 3A, 5A and 10A power variants with full rated current to load and also feature a fully regulated output with low ripple and noise. Unboxed (module only) versions are also available if required, with DIN rail mount options for 1A and 2A models.

Advantages of Switch Mode Technology

Elmdene products using switch mode technology are typically 80-87% efficient. This can save your customers money by reducing their energy bills and carbon footprint.

Switch mode technology provides for lower power consumption, provides cool running and energy efficient products that can result in improved long term reliability

Features:

• Efficient Switch Mode Operation
• Closely Regulated 27.6V Output
• Full Current To Load + 0.5A to Charge Standby Battery
• Universal Mains Voltage Input 90V – 264V ac
• Mains and Battery Monitoring
• Battery Deep Discharge Protection
• Modular Construction for ease of Servicing
• LED Indication:
• Green:  Mains Status
• Yellow: Mains Failure, Output or Battery Fuse Failure, Battery Low or Missing,
  Output Short Circuit or Low Voltage Output
• EPS - Volt Free Fault Output:
• Mains Failure
• GEN - Volt Free Fault Output:
• Output or Battery Fuse Failure, Battery Low or Missing,
  Output Short Circuit or Low Voltage Output
• Electronic short circuit protection 3 & 5A models (under mains power)
• Mains Transient Protection
• FOM 4 or 8 can be fitted to provide 4 or 8 individually fused outputs

Specifications:

• Output (mains on): 27.6V dc nominal
• Load Output: 1 Amp (Optional ratings 2, 3, 5 Amp available)
• Max Battery Capacity: 'R' Box 2x17Ah
• Mains Supply: 90 - 260V @50/60Hz
• Environment: -10C to 40C @ 95%RH
• Enclosure: 'R' - 410H x 390W x 90D hinge lid

For more details on this product range, including part numbers, please refer to the datasheet or contact us on sales@hunters-wholesalers.co.uk for more specific product information and pricing installation and training.
