Eaton, SDR-WEXT-G3-RD-NC, External Wired Sounder (Red Lens/No Cover)

Eaton, SDR-WEXT-G3-RD-NC, External Wired Sounder (Red Lens/No Cover)

SDR-WEXT-G3 (for grade 2 or 3 applications).

The SDR-WEXT is an external siren and strobe unit designed for use with i-on, Menvier and other third-party control units. The siren uses fixed wiring between itself and the control unit or expander.

The SDR-WEXT-G3 contains all features provided by the SDR-WEXT-G2, together with several additional features for enhanced monitoring and system testing.

A capsule range of external sounders, in three colours, with options for wireless, wired and decoy.

Designed for use with i-on and Menvier, new and legacy 868MHz systems. Wired variants also compatible with third-party control units.

Engineer-friendly: a self-supporting lid, built-in spirit-level and revolving fixing holes for ease of installation including on uneven surfaces.
High-power comfort LEDs and LED strobes: provides reassurance for the user.
Common enclosure for entire range: impact-resistant polycarbonate construction in a choice of 3 colours: blue, amber and red.

Key Features:

• Easy to install
• 100 dB(A) sound output
• High-power comfort LEDs
• High-power LED strobes
• Selectable SCB or SAB mode
• Built-in spirit-level
• Self-supporting lid for ease of installation
• Revolving fixing holes
• Engineer (quiet maintenance) mode
• Lid and rear tamper detection
• Selectable cut-off timer
• Choice of siren tones
• Impact-resistant polycarbonate construction

Additional Features:

• Remote self-test input
• Built-in microphone for sounder fault reporting
• Optional battery fault reporting
• Optional monitoring of tamper conditions on Bell (Trigger) input
• Selectable voltage and termination for tamper return

Note: When using the SDR-WEXT-G3 with an i-on/Menvier control unit, make sure that the control unit has firmware version 4.05 or later.

For more details, please refer with our attached datasheet.
