Bell, CSP-BS21/VR, 21 Way Video and Proximity VR System

Bell, CSP-BS21/VR, 21 Way Video and Proximity VR System

These systems have the same features as the standard CSP audio systems but the panel also includes a protected CCD camera for connection to video telephones.

Kit includes:

• Standard wall mounting video telephones
• Stainless steel vandal resistant panel with CCD camera and Paxton compact proximity reader
• Speech unit
• 12V DC power supply
• Surface lock release
• Starter keyfob pack (includes an 'enrolment' card, a 'fail-open' card and 3 user keyfobs & shadow cards)
• Full installation and programming instructions

1) Wall Mounting Video Telephones

The contemporary and stylistic bellissimo video telephone has a slim-line and curvaceous profile complementing most wall furnishings. The 'soft-touch' silicone rubber push buttons are backlit and have clear operating symbols. It is manufactured in white high-impact ABS plastic that imparts high durability and has a 4" flat tube display with variable contrast and brightness, providing a high definition quality picture.

This telephone operates in an innovative electronic mode whereby the supply voltage is 'stepped up' from the controller to achieve proficient operation over long distances.

2) Speech Unit Model 61

This compact unit is fitted to the entrance panel on all our current door entry systems(except as indicated below). The unit provides two-way speech and has an individual volume control for both microphone and speaker. This universal product can be powered from either 12V AC or 12V DC depending on the model of telephone used.

Dimensions: H = 97mm, W = 58mm, D = 24mm

3) Power Supplies

Model 340C (12v DC)
A wall-mounting fused 12v DC regulated power supply rated at 1.5 Amp for use on DC door entry systems and our Access Control systems. It can also be used for directly powering failsafe and continuously rated lock releases. Compliant with EN60950.

Dimensions: H = 140mm, W = 60mm, D = 53mm

Model PS4 (12v DC)
A wall-mounting fused 12v DC regulated power supply rated at 4 Amps for use on video entry systems and for powering high current door release mechanisms. Compliant with EN60950.

Dimensions: H = 110mm, W = 235mm, D = 80mm

A 203 Surface Lock Release as a Standard.
