Videx, 8K1S2E/CL, 1 Way Surface Mount Door Entry Audio Kit with Code lock
- Brand:Videx
- Product Code:8K1S2E/CL
- Availability:Please Call or Email Us to Check Availability
Videx, 8K1S2E/CL, 1 Way Surface Mount Door Entry Audio Kit with Code lock
1 button kit comprising of two 1 button panels with back lit name plates available in surface mounting option, a wall mountable telephone with 3 position volume control for the electronic call tone, a two entrance switcher to ensure the occupant is only talking to one entrance at a time and only releases the entrance from which the call originates and an AC PSU. Up to 2 additional telephones can be added.
Specifications:
- No. Of cores to telephone: 4
- Recommended cable type: CW1308
- Maximum No. Of telephones per call button: 3
- Lock output: 12Vac,
- Telephone model: 3011 (call tone)
- PSU model: 321 (13Vac)
- Amplifier module: 8836M
Kit Includes:
- Outdoor station including a two button speaker module Art.8836M-2, a digital codelock (Art.8800 Codelock module, 2 codes / 2 relays outputs with illumination panel), surface mounting box with module support and hinge Art.8852 plus covering frame Art.8862. Standard finishes: mirror stainless steel for the front plate and aluminium for the module support.
- Art.3011 3000 Series Smart Line wall mount telephone with “door open” push button and electronic call tone with adjustable volume on 3 levels.
- Art.321 Power Supply in a type A 3 module DIN box.
- Packing: box 41x39x7cm, total weight 2.2 Kg.
