Videx, 8K-9S/CL, 9 Way 8000 Series Audio Door Entry Kit - Surface Mount with Code Lock
- Brand:Videx
- Product Code:8K-9S/CL
- Availability:Please Call or Email Us to Check Availability
Videx, 8K-9S/CL, 9 Way 8000 Series Audio Door Entry Kit - Surface Mount with Code Lock
8000 Series audio entry kit with 2 code, 2 relay coded access keypad and 1 call button with back lit name plate. Features include electronic call tone and timed door release (1-99 seconds or latching). The kit comprises an entry panel with either surface or flush frame available in aluminium or black (/BL), a telephone and AC PSU. The telephone includes a three position volume control and is wall mountable. Up to 2 additional handsets can be connected in the same apartment. The programming of access codes is carried out using the codelocks keypad, codes can be 4-8 digits.
8000 Series Audiokit:
The circuitry of the outdoor stations provided with these kits, has a built-in lock relay to enable the electric lock. This reduces the cable requirements to only 4 (“3+1”) between the outdoor station and the intercom. This reduced cable requirement allows longer cable runs and reduced cable sizes to be used between the two units.
The codelock has 2 codes, 2 changeover relay outputs and an override input. It can be programmed from 1-99 seconds or latching output. Comes with 3000 series style audiophone.
Four button door entry kit comprised of:
- Outdoor station including One call button speaker unit Art.8836M-1, flush mounting box with module support and hinge
- Art.8851 plus covering frame Art.8861. Standard finishes: mirror stainless steel for the front plate and aluminium for the module support.
- Art.3011 3000 Series Smart Line wall mount telephone with “door open” push button and electronic call tone with adjustable volume on 3 levels.
- Art.321 Power Supply in a type A 3 module DIN box.
- Art.8881 surface mounting box
Specifications:
- Number of entrances - 9
- No. Of cores to telephone - 4
- Recommended cable type - CW1308
- Maximum No. Of telephones per call button - 3
- Lock output - Dry contact (C NO NC)
- Lock output time - 1-99 Seconds or latching
- Telephone model - 3011 (call tone)
- PSU model - 321 (13Vac)
- Amplifier module - 8836M
- Codelock module - 8800
- Number of codes - 2
- Code length - 4-8
