CQR, MA100T, Single Analyser Single Output + Tamper (White)
- Brand:CQR
- Product Code:MA100T
- Availability:Please Call or Email to Checkout
CQR, MA100T, Single Analyser Single Output + Tamper (White)
A MA100T is Single Output range of analyser designed to work with CQR shock sensors. They use the well-proven Time/Pulse integrator type of system, designed to match various forced-entry modes but without complex setting.
Key Features:
- Single zone universal shock sensor analyser
- Uses the well proven time/pulse integration system
- Features a wide-range sensitivity control, auto-reset alarm relay & LED indicator
- Can be located within an alarm control panel or mounted externally
- Microswitch cover removal tamper
- Can be used to supervise up to 10 shock sensor modules
- Dimensions: 80 x 53 x 25 mm.
Specifications:
- Supply Voltage: 10.5 - 15vDC
- Supply Current: 30mA
- Sensor loops: 1
- Indicators: 1
- Sensitivity: 1
- Reset: Auto
- Alarm relay: open on alarm, 1 amp, 60v
- Tamper Switch: 250v 1A
- Size mm: 80 x 53 x 25
- Colours: White.
Contact us on sales@hunters-wholesalers.co.uk for more specific product information and pricing installation and training.
